Farm & Agricultural Trench Drains
Agricultural and farm environments demand drainage systems that can handle heavy equipment, organic runoff, and exposure to fertilizers, feed, and cleaning agents. Whether in barns, milking parlors, equipment yards, or processing sheds, effective trench drainage helps maintain safe, sanitary, and stable conditions. TrenchDrainCo trench drain systems are built for reliability in demanding rural environments — delivering strength, chemical resistance, and ease of maintenance for decades of continuous use.
Key Requirements
-
Load Rating
Typically C250 to F900, depending on the farm operation.
• Barns, feed areas, and livestock corridors: C250–D400.
• Equipment yards and tractor access zones: D400–E600.
• Processing and washdown areas: C250–D400 pedestrian-rated with chemical-resistant channels.
Heavy farm vehicles and loaders require high load-bearing trench systems with reinforced edges.
-
Material Durability
Farm drains must resist water, organic acids, cleaning chemicals, and thermal cycles.
• Fiber-Reinforced Concrete (FRC) or Polymer Concrete channels for maximum load and impact resistance.
• HDPE or PVC channels for lightweight, corrosion-resistant installations in barns or pens.
• Galvanized or stainless steel edge rails for added protection against chipping and corrosion.
• Cast-iron or ductile-iron grates for equipment traffic.
• Stainless steel grates for washdown or food-grade areas.
-
Site Conditions
• Farm sites experience continuous moisture, sediment, and organic debris.
• Drainage should prevent standing water to avoid slip hazards and disease transmission.
• Systems must integrate with retention ponds or on-site treatment for environmental compliance.
• Surfaces should slope (1–2%) toward drains for efficient runoff and cleaning.
• Freeze–thaw resistance is critical for outdoor or unheated structures.
-
User Requirements
• Durability: Handle tractors, skid steers, and livestock without cracking or edge failure.
• Chemical resistance: Withstand fertilizers, detergents, and manure acids.
• Hygiene: Smooth channel surfaces for easy flushing and debris removal.
• Safety: Non-slip, heel-proof grates to protect workers and animals.
• Maintenance: Simple cleaning access with removable grates and sediment baskets.
Recommended TrenchDrainCo Systems
TrenchDrainCo 300 Series
Heavy-duty fiber-reinforced concrete trench drain for drive lanes, barns, and machine sheds.
TrenchDrainCo HDPE Agricultural Series
Lightweight, corrosion-resistant channel for barns, pens, and processing sheds.
TrenchDrainCo Stainless Washdown System
316 stainless steel channel and grate system for dairies and food-grade zones.
TrenchDrainCo LEO 1200
Ductile-iron grate system for high-load equipment yards and outdoor drainage.
Engineering Notes
When designing trench drains for agricultural facilities:
- Match material type to environment — polymer concrete or stainless for corrosive areas, FRC for structural zones.
- Include catch basins to intercept sediment, straw, or feed waste before outflow.
- Integrate drainage into manure management or stormwater retention systems.
- Ensure channel widths and flow rates align with washdown and rainfall volume.
- Use sealed joints or liners in areas exposed to harsh cleaning agents or effluents.
- For animal areas, select grates that prevent hoof entrapment while providing traction.
