Dog Kennel Trench Drains
Dog kennels and animal care facilities require drainage systems that prioritize hygiene, odor control, and safety. Standing water, bacteria growth, and poor washdown drainage can compromise animal health and facility sanitation. TrenchDrainCo trench drain systems are designed to meet the rigorous demands of kennels, grooming stations, and veterinary facilities — providing superior cleanability, slip resistance, and long-term durability for daily operations.
Key Requirements
-
Load Rating
Typically A15 to C250, depending on traffic type and cleaning methods.
• Kennel corridors and runs: A15–B125 for pedestrian and animal traffic.
• Outdoor play or cleaning zones: B125–C250 for light maintenance vehicles and carts.
• Veterinary service areas: C250 for rolling cages and sanitation equipment.
Drain systems should accommodate frequent washdowns and heavy water flow without overflow or clogging.
-
Material Durability
Kennel drainage systems are exposed to water, cleaning chemicals, disinfectants, and pet waste.
• HDPE or PVC channels for corrosion-resistant, watertight performance.
• Stainless steel channels and grates (304 or 316) for superior sanitation and odor control.
• Polymer concrete channels for high rigidity and durability in permanent installations.
• Composite or stainless grates for slip resistance and smooth surfaces safe for paws.
• Rounded interior profiles prevent residue buildup and simplify cleaning.
-
Site Conditions
• Floors should slope 1–2% toward the trench drain to prevent standing water in runs and washing areas.
• System design must integrate with sanitary sewer or treatment systems compliant with local regulations.
• Smooth internal surfaces promote fast flow and reduce bacteria growth.
• Use chemical-resistant seals and joints for long-term watertightness.
• Indoor systems must control odors and resist microbial growth through easy cleaning and nonporous materials.
-
User Requirements
• Hygiene: Smooth, non-porous channels prevent bacterial and odor buildup.
• Safety: Non-slip, paw-safe grates that protect animals and handlers.
• Quiet operation: Rattle-free systems to minimize noise and animal stress.
• Ease of cleaning: Quick grate removal and debris strainers simplify maintenance.
• Odor control: Airtight connections and slope optimization to prevent stagnant water.
• Aesthetic integration: Sleek stainless options for modern veterinary or grooming environments.
Recommended TrenchDrainCo Systems
TrenchDrainCo 600 Series
6" HDPE channel system ideal for kennel runs and indoor washdown zones.
TrenchDrainCo Stainless Kennel Series
304 or 316 stainless steel trench drain designed specifically for kennels and animal care facilities — hygienic, durable, and odor-resistant.
TrenchDrainCo Polymer Concrete Sanitary Series
Heavy-duty option for long-term installations with rigid performance and chemical resistance.
TrenchDrainCo Sierra 5 Shallow Linear System
Shallow, low-profile drain for grooming areas, indoor runs, and retrofit applications.
Engineering Notes
When designing trench drains for kennels and veterinary facilities:
- Install drains along central corridors or rear wall lines for effective washdown flow.
- Select stainless steel or polymer concrete for high-sanitization areas such as surgical and grooming rooms.
- Confirm grate openings are paw-safe and heel-proof (≤ 6 mm).
- Integrate sediment baskets or strainers to capture fur, debris, and solids.
- Use watertight, sealed systems to prevent leakage into subfloor or kennel foundations.
- Consider heated drain options for outdoor kennel runs in cold climates.
Hygienic. Durable. Paw-safe.
Contact TrenchDrainCo to design a trench drain system tailored for kennels, veterinary facilities, and animal-care environments.
